Francis Hydro Turbine 50kW-20MW Horizontal Generator Stainless Steel
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 50000 |
|
Detail Information |
|||
| Model NO.: | ZDJJP131 | Output Type: | DC |
|---|---|---|---|
| Bearing Support: | Hanging Type | Speed: | Low Speed |
| Bearing Number: | 2 | Runner Material: | Stainless Steel |
| Efficiency: | Up To 90% | Insulation Class: | F/F |
| Capacity: | 50kw-20MW | Generator Type: | Brushless |
| Voltage: | 400V-6300V | Turbine Type: | Francis, Pelton, Turgo, Kaplan |
| Dimensions: | 300CMx200cmx150cm | Water Head: | 10m - 700m |
| Frequency: | 50Hz / 60Hz | ||
| Highlight: | Francis Hydro Turbine stainless steel,horizontal Francis Hydro Turbine generator,Francis Hydro Turbine 50kW-20MW |
||
Product Description
5680kw Micro Mini Small Generator Turbine Francis Kaplan Pelton Turgo Water Turbine
Product Description
This micro/small/mini power generator turbine includes Kaplan, Pelton, Turgo, and Francis water turbine models, designed for efficient power generation across various applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Water head | 10m - 700m |
| Power range | 50kW - 20MW |
| Frequency | 50Hz / 60Hz |
| Generator voltage | 400V, 800V, 6300V, 10500V |
| Layout mode | Horizontal or vertical |
| Material | Stainless steel ZG0Cr13Ni4Mo |
| Excitation | Brushless or static excitation system |
| Lifespan | 50 years |
| Runner diameter | 0.35m - 4m |
| Generator insulation | F/F |
Product Features
- Compact structure with high efficiency
- Adaptable to wide range of water heads (20m-700m)
- Simple structure with stable operation
- Radial-axial flow design for optimal performance
- Proven technology with units exceeding 700,000kW capacity
Application Scenarios
Our Advantages
- 20+ years of customization experience
- Exceptional safety and cooling performance
- High energy efficiency and conservation
- Minimal system failure points for enhanced reliability
- Broad applicability across turbine types and operating conditions
Related Products
Our Services
- Exploration and design of hydropower plants
- Design and manufacturing of turbine generator sets
- EPC for electromechanical equipment
- Pre-sales services and technical consultancy
- Installation, commissioning, and maintenance services
Certifications & Cases
Packaging & Shipping
Frequently Asked Questions
Q: Are you a trading company or a manufacturer?
A: We are a hydro turbine generator manufacturer with over 15 years of experience. Our factory is in Sichuan, about 2 hours from Shuangliu Airport.
Q: What kind of water turbine should I choose?
A: We need to know water head, flow rate, voltage level, frequency, and operation mode to recommend the best solution.
Q: Can you do the EPC for the hydro power plant?
A: Yes, we can design, produce, and install the equipment, dispatching technicians for installation.
Q: What is the packing of the equipment?
A: We use wooden boxes to protect the product during shipping.
Q: Who can help if my turbine shuts down?
A: Our engineers are available 24/7 to troubleshoot and resolve any issues.
