Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Vertical Hydro Turbine
,Vertical Hydro Turbine 1200kw
,1200kw hydroelectric power plant generator
Hydro Electrical Generator Kaplan Hydro Turbine Generator 1200kw
Hydro turbine generator is driven directly or indirectly by hydro turbine. The rotating speed is less than 1500r/min, with horizontal and vertical arrangement. Excitation mode with brushless and static silicon type. Components including stator, rotor, base frame, bearing, excitation motor or collecting ring. The outlet voltage from 400V to 13.8KV, and frequency could be 50Hz or 60Hz, output from 50Kw to 50Mw. Our generator is high efficiency, reliable, manufacture and tests all follow related IEC standards.
Ø Frequency: 50 or 60Hz;
Ø Voltage scope: 0.38-13.8KV;
Ø Arrangement: vertical and horizontal;
Ø Speed scope: 93.75-1500r/m;
Ø Power factor: 0.8 – 1;
Ø Insulation Level: F/F;
Ø Output scope: 50Kw- 50Mw
| Place of Origin: | Sichuan, China |
| Brand Name: | Customized |
| Warranty: | 1 year |
| Application: | Hydropower Plant |
| Certificate: | ISO9001 |
| Lifetime | 35 years |
-
185kW Vertical Hydro Turbine with 20m Head and 3.5 m³/s Flow Kaplan Cross Flow Turbine Generator
185kW Vertical Hydro Turbine - Small Micro Water Kaplan Cross Flow Turbine Generator Our 185kW Small Vertical Kaplan Turbine and Cross Flow Turbine with Hydro Electric Generator delivers reliable power generation for small to medium-scale hydropower applications. Available Turbine Generator Series ...
-
Fixed Blade Axial Flow Propeller Hydro Turbine On Grid Off Grid 50KW-20MW
Kaplan Axial Flow Propeller Hydro Turbine Axial Flow Turbine is used in hydropower plants with low and middle water head commonly ranging from 3m to 30m. It can be divided into Propeller /Fix Blade Type (ZD) and Kaplan/ Movable Blade Type (ZZ), Propeller turbine is used in the power plant whose flow ...
-
60Hz Vertical Hydro Turbine Francis Turbine Generator For Hydroelectric Power Station
Francis Turbine Hydro Turbine Generator Hydroelectric Power Station Our Main Products: Francis, Kaplan, Pelton, Turgo, Tubular Turbine Generator Unit Place of Origin: Sichuan, China Brand Name: Customized Warranty: 1 year Application: Hydropower Plant Certificate: ISO9001 Lifetime 35 years FAQ Q1: ...
-
50HZ Francis Hydraulic Turbine 100m Water Head Automatic On Grid
Hydro Francis Turbine Generator Price With Governor Supplier The original Francis turbine has been modified from time to time to improve its efficienty, and today, an efficienty of more than 93% has been reached. Francis turbine is a versatile one and can work over a very wide range of heads from ...
-
Horizontal Vertical Hydro Turbine Micro Francis Turbine 60Hz 92.5% Efficiency
Hydraulic Turbines With Generator Micro Francis Turbine Generator Mini Francis Turbine Francis Turbine The water flow of the Francis turbine is sprayed from the horizontal to the center of the rotating wheel (inhaled), and then turned into the direction of exit, the water flow to the wheel in the ...
-
Adjustable Hydropower Plant Turbine 470kw 0.8 Power Factor
Cities Skylines Hydro Power Plant Hydro Power Plant Generate Electricity 470kw Turbine distributor It consists of guide vane, guide vane lever, shaft sleeve, front cover, back cover, etc. It can form or change number of swirls of water flow to adjust turbine discharge according to variation of load. ...
-
5Mw Francis Vertical Hydro Turbine 120m Water Head Variable Pressure
5 Mw Francis Hydro Turbine/Francis Turbina Generator 500kw Water Francis Turbine Francis Water Turbine The original Francis turbine has been modified from time to time to improve its efficienty, and today, an efficienty of more than 93% has been reached. Francis turbine is a versatile one and can ...
-
600kw Kaplan Hydro Turbine Radial Flow 10m Water Head 7.65 M3/S Axial Overpressure
Kaplan Turbine Generator 600kw Water Head 10m Kaplan Turbines are impeller-turbines, where the runner turns in the water flow like a ship´s propeller. Kaplan water turbine is axial overpressure water turbine, which has a radial inflow, outflow, however axial. It is used for high flow rates and low ...
