50HZ Francis Hydraulic Turbine 100m Water Head Automatic On Grid
Product Details:
| Place of Origin: | Sichuan |
| Brand Name: | Wawushan |
| Certification: | ISO9000 |
| Model Number: | HLA-072 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 150 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1 set 4-5 month |
|
Detail Information |
|||
| Water Head: | 100 M | Water Flow: | 6.5 M³/s |
|---|---|---|---|
| Runner Material: | Stainless Steel | Efficiency: | 91.2% |
| Frequency: | 50HZ | Power Factor: | 0.80 |
| Rated Efficiency: | 91.2% | ||
| High Light: | 50HZ On Grid Francis Hydraulic Turbine,100m Head Francis Hydraulic Turbine,100m Head turbine type francis |
||
Product Description
Hydro Francis Turbine Generator Price With Governor Supplier
The original Francis turbine has been modified from time to time to improve its efficienty, and today, an efficienty of more than 93% has been reached. Francis turbine is a versatile one and can work over a very wide range of heads from 25m onwards to 550m. This is a reactin type of turbine where water is admitted at high pressure into the runner, and pressure energy is converted into mechanical energy, because of the reaction of water when travling over the curved vanes. As the pressure inside the turbine varies, Francis turbine is also called a variable pressure turbine.
| Place of Origin: | Sichuan, China |
| Brand Name: | Customized |
| Warranty: | 1 year |
| Application: | Hydropower Plant |
| Certificate: | ISO9001 |
| Lifetime | 35 years |
Quick Details
