Fixed Blade Vertical Kaplan 100 Kw Hydroelectric Generator 16m Water Head
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Certification: | ISO9000 |
| Model Number: | ZDJP-082 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 180 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Layout: | Vertical | Runner Blade: | Fixed |
|---|---|---|---|
| Water Head: | 16 M | Water Flow: | 4.2 M³/s |
| Color: | Yellow | Product Name: | Vertical Kaplan Turbine |
| High Light: | Kaplan 100 Kw Hydroelectric Generator,Vertical 100 Kw Hydroelectric Generator,Fixed Blade pelton francis and kaplan turbine |
||
Product Description
Kaplan Turbine Vertical Kaplan Turbine Generator Unit
Kaplan turbine is a kind of turbine suit to low water head 3-45 meters, and with certain big flow, normally divided into fixed blades and adjustable blades turbine. Main components including: runner, draft cone, water chamber, guide vane, bearing, and main shaft. The spiral case could be steel or concrete.
1, Suitable water head : 3-45m
2, Output scope : 100Kw -30Mw
3, Runner diameter : 80cm -400cm
4, Runner material : stainless steel
5, Arrangement type : Vertical
| Place of Origin: | Sichuan, China |
| Brand Name: | Customized |
| Warranty: | 1 year |
| Application: | Hydropower Plant |
| Certificate: | ISO9001 |
| Lifetime | 35 years |
Kaplan Runner
Kaplan runner with 3 to 6 blades, fixed blades runner, blades are casted and then welded on the runner hub, and bolts connection with draft cone. Regarding the adjustable blades runner, the hub is designed to be hollow, and a control rod is designed in the shaft middle to change blades angle in order to suit different flow.
