Vertical Turbine Hydro Electric Power System 2000kw 0.8-0.9 Power Factor
Vertical Turbine Hydro Electric Power System
,Hydro Electric Power System 2000kw
,2000kw Hydro Power System Design
our service
Outline specification of all hardware (turbine, screen cleaner etc.)
Outline specification of electrical and hydraulic systems
Site plans and general arrangement drawings
Design drawings to support consent applications
Detailed design
The detailed design builds on the already competed outline design. The key components are:
Specification and procurement of any geotechnical investigations required
Design of foundations
Construction design of concrete structures including reinforcement design
Detail design and specification of all fabricated parts (intake screens, fish pass etc.)
Design and specification of on-site electrical systems
Design and specification of all hydraulic systems
Specification of all hardware (turbine, screen cleaner etc.)
Construction Method Statement
Fulfilling the ‘designers’’ responsibilities under the CDM Regulations
Writing the tender package, obtaining and appraising quotes from civil engineering contractors
Construction-stage project plan
This is the full construction design and equipment specification, including all mechanical, electrical and civil engineering aspects.
The result is the construction design package which contains everything required to issue tenders for the civil engineering part of the installation phase and then go on to build it. It also includes the full hardware specification so that the turbine, screen cleaner and all of the ancillary parts can be ordered.
| machine type | Francis |
| generator mount | vertical |
| capacity | 50kw-20MW |
| generator type | brushless |
| voltage | 400V |
| power factor | 0.8-0.9 |
-
