Vertical Micro Hydro Kaplan Turbine Generator 6000kw Adjustable Blade

Vertical 6000kw Water Kaplan Turbine Generator For Micro Power Plant

overview

1. Suitable for the development of low water head larger flow of water resources;

2. Appliceable to large and small head change load changes of power plant;

3. For the low head,head and power changed greatly power station,can stably under various working conditions;

4. This machine is a vertical shaft device,has the advantages of simple structure,convenient repair,equipment,low price,easy to realize the direct drive etc.

5. The Kaplan blade is generally operated by the oil pressure relay installed in the body of the runner, which can rotate according to the change of head and load, so as to maintain the optimal coordination between the Angle of the guide vane and the Angle of the blade, thus improving the average efficiency. Kaplan turbine The highest efficiency of this kind of turbine has exceeded 94%. However, this kind of kaplan turbine needs a mechanism to operate the rotation of the blade, so the structure is more complex and the cost is higher.

Standard followed as below:

1. GB/T15468-95 Fundamental technical requirements for hydraulic turbine
2. GB10969-95 Specifications for water passage components of hydraulic turbines neq IEC 193No.1:1977
3. GB/T7894-2001 Fundamental technical requirements for hydraulic turbine generator
4.  GB9652-95 Specifications of governors and pressure oil supply units for hydraulic turbines
5.  GB10585-97 Fundamental requirements of excitation system for medium and small generators
6. GB11805-97 Fundamental technical requirements for automatic control components and their related system for medium and small hydro   generating sets
7.  GB8564-97 Specifications for installation of hydraulic-turbine and generator units
8. GB/T15469-95 Cavitation pitting evaluation in reaction trubines
9.  JB/DQ1428-97 Quality grading for medium and small hydraulic turbines
10. JBT6752-93 Specifications for static balancing test of medium and small hydraulic turbine runner
11. JBDQ3467-97 Quality grading for medium and small hydraulic turbine generators
12. GB/T14478-1993 Fundamental technical requirements for large and medium inlet valves of hydraulic turbines
13. JB/T8527-1989 Metal sealed butterfly valve
14. JB/T5299-1998 Hydraulic control slow-closing butterfly valve

Specification

Why choose us?

1. More than 20 years of industry experience, install commissioning more than 150 equipment each year

2. Provide complete proposal for hydro power plant from water to wire

3. Abundant foreign power plant project implementation experience such as France, Japan, USA, South Africa, Sri Lanka, Iran, Southeast Asia

4. Design and manufacture of hydro power generator with voltage 400V,6.3KV . capacity exceed 1000kw with 400V

FAQ

1.You are a trading company or a manufacture?

We are a hydro turbine generator manufacture with over 20 years of experiences, Our factory is in the Sichuan you will take 2 hours driving after you reach Shuangliu Airport, pay a visit to our factory you will know more about us.

2.What Kind of water turbine should I choose?

We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, automation level from you to work out the solution

3: Can you do the EPC for the hydro power plant?

Yes, We can design, producing and install the equipment, we will dispatch technologist and workers to install the equipment.
