185kW Small Vertical Hydro Turbine 300r/Min 120cm Runner
185kW Small Vertical Hydro Turbine
,Vertical Hydro Turbine 300r/min
,300r/min water turbine power generator
185kW Small Vertical Kaplan Turbine
1. Basic Data
| Item | Parameter |
| Capacity | 2×185KW |
| Rated Head | 4.85m |
| Rated Flow | 2x4.82 m3/s |
| Vertical Kaplan Turbine | |
| Turbine Type | Vertical Kaplan Turbine |
| Turbine Modle | ZD680-LMY-120 |
| Rotation Speed | 300r/min |
| Runner Diameter | 120cm |
| Blades | Fixed |
| Runner Material | Stainless Steel (06Cr13Ni4Mo) |
| Cooling Way of Bearing | Water Cooling |
| Hydro Electric Generator | |
| Generator Type | Synchronize, Vertical |
| Generator Modle | SF185-20/1180 |
| Rated Voltage | 400V |
| Rated Power Factor | 0.8 (Lagging) |
| Frequency | 50 Hz |
| Insulation Class | F/F |
| Braking Way | Oil Braking (from governor) |
| Excitation system | SCR |
Description of type:
ZD680-LMY-120 type turbine:
Z — Kaplan Turbine
D — Fixed Blades
680 — Code of runner
L — Vertical Shaft
MY—Pressure and Open Type diversion channel
120 — Diameter of runner (cm)
-
