High Head Water Turbine with Stainless Steel Runner and Brushless Excitation Control System for 50-700 Meters Head Range
Product Details:
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | T-202502 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 60000 |
| Packaging Details: | standard |
| Delivery Time: | 6 months |
| Payment Terms: | T/T |
| Supply Ability: | 100 sets per year |
|
Detail Information |
|||
| Control System: | Brushless Excitation | Runner Diameter: | 1.0 M |
|---|---|---|---|
| Water Head: | 180 M | Guide Vane: | Stainless Steel |
| Keyword: | High Head Water Turbine | Rotation: | 1000RPM |
| Runner Material: | Stainless Steel | Headrange: | 50-700 Meters |
| Highlight: | Stainless Steel Runner High Head Water Turbine,Brushless Excitation Control System Hydraulic Turbine,50-700 Meters Head Range Axial Flow Turbine |
||
Product Description
High Head Water Turbine
Advanced hydroelectric solution designed to harness water energy from heights ranging 50-700 meters, featuring tubular turbine technology with axial flow mechanism for optimal energy conversion.
Key Specifications
Power Range
1400-2200 KW
Head Range
50-700 Meters
Rotation Speed
1000 RPM
Operating Temperature
-10°C to 50°C
Frequency
50Hz/60Hz
Product Features
- Model: XJ02-W-50/1*11 with tubular turbine design
- Efficient axial flow turbine mechanism for optimized performance
- Integrated axial flow generator for maximum power output
- Brushless excitation control system for reliability
- Stainless steel guide vane and runner construction
- Compatible with bulb turbine generator systems
- Durable blue corrosion-resistant coating
- Runner diameter: 1.0 meter
Technical Parameters
| Operating Temperature | -10°C to 50°C |
| Phase Type | 3Phase/1phase |
| Control System | Brushless Excitation |
| Model | XJ02-W-50/1*11 |
| Color | Blue |
| Type | Hydraulic Turbine |
| Runner Diameter | 1.0 M |
| Guide Vane Material | Stainless Steel |
| Rotation Speed | 1000 RPM |
| Runner Material | Stainless Steel |
Applications
Ideal for hydroelectric power plants in regions with significant water head differences, including river dams, irrigation canals, and small to medium-scale hydropower stations. Suitable for both new installations and upgrades to existing facilities.
Customization Services
Wawushan offers tailored customization for the High Head Water Turbine model XJ02-W-50/1*11, including design modifications, frequency adjustments, and enhanced durability features to meet specific project requirements.
Support and Services
Comprehensive technical support including installation assistance, performance testing, maintenance services, and spare parts availability. Our expert team provides troubleshooting and system integration solutions throughout the turbine's lifecycle.
