Vertical Pelton Wheel Micro Hydro Generator 500RPM 91% Efficiency
Vertical pelton wheel micro hydro generator
,pelton wheel micro hydro generator 500RPM
,500RPM pelton wheel generator kit
2000kw Micro Pelton Hydro Turbine Generator For Mini Hydro Power Plant
overview
Pelton turbine also called a free-jet turbine or Pelton wheel, a type of impulse turbine.
Water Passes through nozzles and strikes spoon-shaped buckets or cups arranged on the periphery of a runner, which causes the runner to rotate, producing mechanical energy. The runner is fixed on a shaft, and the rotational motion of the turbine is transmitted by the shaft to a generator.
The impulse type turbines are the best election for high head and small discharge hydraulic power resources. They have compact structure, small size, high efficiency and need fewer investments. They have been divided into Turgo and Pelton type.
The impulse type turbines made by Fuchun, are ranging from 80 to 1, 000m in water head, 200kW to 20MW in capacity and 0.55 to 2.3 in runner diameter. Theirs shaft arrangements are either vertical or horizontal and they may have single nozzle, twin or multi-nozzles.
Specification
| Name | 2000kw Pelton Hydro Turbine Generator |
| Water Head | 150m |
| Runner Diameters | 1.7m |
| Capacity | 2000KW |
| Frequency | 50HZ |
| Generator Voltage | 6300V |
| Layout pattern | vertical |
| Material(blades) | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Why choose us?
1. More than 20 years of industry experience, install commissioning more than 150 equipment each year
2. Provide complete proposal for hydro power plant from water to wire
3. Abundant foreign power plant project implementation experience such as France, Japan, USA, South Africa, Sri Lanka, Iran, Southeast Asia
4. Design and manufacture of hydro power generator with voltage 400V,6.3KV . capacity exceed 1000kw with 400V
FAQ
1.You are a trading company or a manufacture?
We are a hydro turbine generator manufacture with over 20 years of experiences, Our factory is in the Sichuan you will take 2 hours driving after you reach Shuangliu Airport, pay a visit to our factory you will know more about us.
2.What Kind of water turbine should I choose?
We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, automation level from you to work out the solution
3: Can you do the EPC for the hydro power plant?
Yes, We can design, producing and install the equipment, we will dispatch technologist and workers to install the equipment.
-
