1000KW Capacity Turgo Impulse Turbine with Stainless Steel Runner for 98m Water Head Hydro Power
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | XJ-003 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 120 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Runner Material: | Stainless Steel | Body: | Steel Casting |
|---|---|---|---|
| Capacity: | 1000kw | Runner Diameter: | 0.75 M |
| Flow: | 1.34 | Head: | 98 M |
| Highlight: | 98m Head Turgo Impulse Turbine,400V 50HZ Turgo Impulse Turbine,400V 50HZ turgo water turbine |
||
Product Description
Hydro Power Turgo Impulse Turbine
1000kW Turgo hydro turbine generator designed for efficient hydroelectric power generation with advanced impulse turbine technology.
Overview
The Turgo impulse turbine operates effectively within water head ranges of 30 to 300 meters. Its unique design features a jet flow center angled at 22.5° to the runner gyration plane, with water flow contracted by spray nozzles entering one side of the runner and exiting from the opposite side.
Horizontal units offer simple structure, convenient maintenance, reduced plant height, and minimized excavation depth requirements. Vertical units feature compact plant dimensions, support multiple nozzles (up to six), provide high specific speed, offer greater capacity in smaller sizes, and deliver lightweight construction advantages.
Technical Specifications
| Specification | Value |
|---|---|
| Name | 1000kW Turgo Water Turbine Generator |
| Water Head | 98.0m |
| Runner Diameter | 0.75m |
| Capacity | 1000KW |
| Frequency | 50HZ |
| Generator Voltage | 400V |
| Layout Pattern | Vertical |
| Blade Material | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Key Advantages
- Operates effectively between Francis and Pelton turbine ranges
- Minimizes over-pressure effects on penstock systems
- Higher operating speeds reduce weight and overall costs
- Maintains high efficiency across wide flow variations
- Superior resistance to abrasive wear and tear
- Simplified operation and maintenance procedures
Complete Project Package
1. Project Documentation & Contract
Verification and audit of submitted documents, followed by contract signing
2. Engineering Design
Complete equipment selection, overall layout design, personnel selection, and technical solution approval
3. Equipment Procurement & Logistics
Turbo generator sets with auxiliary systems, construction materials, tools, and spare parts
4. Civil Construction
Comprehensive civil construction work within power plant parameters
5. Operation & Maintenance
Technical counseling, regular maintenance, personnel training programs, and general overhaul services
6. Installation & Testing
Complete system installation, testing, and trial runs for all power plant components
7. Spare Parts Supply
Long-term availability of spare parts and consumables
