Fixed Blade 1300kw Kaplan Hydro Turbine Generator For Micro Power Plant
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Model Number: | ZDJP-004 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD+30000-200000+unit |
| Packaging Details: | plywood |
| Delivery Time: | 180 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Runner Material: | Stainless Steel | Guide Vane: | Stainless Steel |
|---|---|---|---|
| Layout: | Vertical | Runner Blade: | Adjustable |
| Runner Diameter: | 1.4 M | Flow: | 11.02 M³/s |
| Highlight: | 1300kw Kaplan Hydro Turbine Generator,micro power plant Kaplan Hydro Turbine,1300kw kaplan type turbine |
||
Product Description
1300kw Kaplan water turbine generator
overview
We supply a double regulation system of fixed blade and adjustable blade With a double regulation system, Kaplan turbines provide high efficiency
over a broad range of configurations
The vertical configuration of the Kaplan turbine allows for larger runner diameters (above 10 m) and increased unit power.
Our Kaplan turbines also keep the environment in mind. Engineered with a "fish-friendly“ structure, to improve the survival rate of migrating species,
and water-lubricated bearings and water-filled hubs to prevent water pollution.
Our Kaplan turbines are constructed with oil-free hubs where the oil traditionally filling the hub has been replaced by water and all brushes are made
of self-lubricating material. This eliminates the risk of oil leakage in the water.
Kaplan Turbine Product Features
1. Suitable for the development of low water head larger flow of water resources;
2. Appliceable to large and small head change load changes of power plant;
3. For the low head,head and power changed greatly power station,can stably under various working conditions;
4. This machine is a vertical shaft device,has the advantages of simple structure,convenient repair,equipment,low price,easy to realize the direct drive etc.
5. The Kaplan blade is generally operated by the oil pressure relay installed in the body of the runner, which can rotate according to the change of head and load, so as to maintain the optimal coordination between the Angle of the guide vane and the Angle of the blade, thus improving the average efficiency. Kaplan turbine The highest efficiency of this kind of turbine has exceeded 94%. However, this kind of kaplan turbine needs a mechanism to operate the rotation of the blade, so the structure is more complex and the cost is higher.
Specification
| Name | 1300kw Kaplan water turbine generator |
| Water Head | 15.0m |
| Runner Diameters | 1.4m |
| Capacity | 1000KW |
| Frequency | 50HZ |
| Generator Voltage | 6300V |
| Layout pattern | vertical |
| Material(blades) | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Why choose us?
1. More than 20 years of industry experience, install commissioning more than 150 equipment each year
2. Provide complete proposal for hydro power plant from water to wire
3. Abundant foreign power plant project implementation experience such as France, Japan, USA, South Africa, Sri Lanka, Iran, Southeast Asia
4. Design and manufacture of hydro power generator with voltage 400V,6.3KV . capacity exceed 1000kw with 400V
FAQ
1.You are a trading company or a manufacture?
We are a hydro turbine generator manufacture with over 20 years of experiences, Our factory is in the Sichuan you will take 2 hours driving after you reach Shuangliu Airport, pay a visit to our factory you will know more about us.
2.What Kind of water turbine should I choose?
We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, automation level from you to work out the solution
3: Can you do the EPC for the hydro power plant?
Yes, We can design, producing and install the equipment, we will dispatch technologist and workers to install the equipment.
