Axial Micro Kaplan Turbine 300kw 4.21m3/S 9m Water Head Brushless
9m Head Micro Kaplan turbine
,Micro Kaplan turbine 300kw
,Brushless Axial water turbine
300kw Micro Kaplan Hydro Turbine Generator For Home
overview
Kaplan type turbine is widely used in electricity production which is suitable for micro hydro power plant work at low water head and big flow. Kaplan turbine generator has dual adjustment performance which means the guide blades and runner blades are both adjustable. therefore, Kaplan turbine generator is able to keep stable operation and high efficiency whil the heads and loads change greatly.
advantage
The Axial water turbine((Kaplan)) is suitable for low and medium heads from 2 to 30 meters. the runner of machine can work with fixed and adjustable accordingly to situtation on site.the fixed blade propeller water turbine is used for medium and small sites with small variation of head and load, and the Kaplan turbine is used for medium and large sites with large variation of head and load.
Kaplan turbine is the most widely used water turbine for low head run-off-rive small (200KW-3000KW) hydro power plant with its simple structure and big flow discharge capacity.
Specification
| Name | 300kw Micro Kaplan Hydro Turbine Generator |
| Water Head | 9.0m |
| Runner Diameters | 1.2m |
| Capacity2 | 300KW |
| Frequency | 50HZ |
| Generator Voltage | 400V |
| Layout pattern | vertical |
| Material(blades) | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Why choose us?
1. More than 20 years of industry experience, install commissioning more than 150 equipment each year
2. Provide complete proposal for hydro power plant from water to wire
3. Abundant foreign power plant project implementation experience such as France, Japan, USA, South Africa, Sri Lanka, Iran, Southeast Asia
4. Design and manufacture of hydro power generator with voltage 400V,6.3KV . capacity exceed 1000kw with 400V
FAQ
1. You are a trading company or a manufacture?
We are a hydro turbine generator manufacture with over 20 years of experiences, Our factory is in the Sichuan you will take 2 hours driving after you reach Shuangliu Airport, pay a visit to our factory you will know more about us.
2. What Kind of water turbine should I choose?
We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, automation level from you to work out the solution
3: Can you do the EPC for the hydro power plant?
Yes, We can design, producing and install the equipment, we will dispatch technologist and workers to install the equipment.
-
