100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner

100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner
100kW Mini Generator for Hydro Power Plant Impact Turbine Units Product Overview Our 100kW micro/small/mini power generator turbine is available in Kaplan, Pelton, Turgo, and Francis water turbine configurations, designed for efficient hydroelectric power generation. Product Specifications Water ...
Place of Origin:China
Brand Name:WaWuShan
Certification:ISO
Model Number:SFW-200KW (2000KW)
Minimum Order Quantity:1
Price:200000
Product Custom Attributes
Highlight

100kw Francis hydro turbine generator

,

stainless steel Francis turbine runner

,

400V-6300V hydro turbine generator

Model NO.:
CJA475
Output Type:
DC
Bearing Support:
Hanging Type
Bearing Number:
2
Runner Material:
Stainless Steel
Efficiency:
Up To 90%
Insulation Class:
F/F
Capacity:
50kw-20MW
Generator Type:
Brushless
Voltage:
400V-6300V
Turbine Type:
Francis, Pelton, Turgo, Kaplan
Dimensions:
300CMx200cmx150cm
Water Head:
10m - 700m
Frequency:
50Hz / 60Hz
Runner Diameter:
0.35m - 4m
Material:
Copper
Product Description
100kW Mini Generator for Hydro Power Plant Impact Turbine Units
Product Overview
Our 100kW micro/small/mini power generator turbine is available in Kaplan, Pelton, Turgo, and Francis water turbine configurations, designed for efficient hydroelectric power generation.
Product Specifications
Water head 10m - 700m
Power range 50kW - 20MW
Frequency 50Hz / 60Hz
Generator voltage 400V, 800V, 6300V, 10500V
Layout mode Horizontal or vertical
Material Stainless steel ZG0Cr13Ni4Mo
Excitation Brushless or static excitation system
Lifespan 50 years
Runner diameter 0.35m - 4m
Generator insulation F/F
Technical Features
The Francis turbine features a compact structure and high efficiency, capable of adapting to a wide range of water heads. Water flows through the runner radially and exits axially, making it a radial-axial turbine.
With a simple structure, stable operation, and high efficiency, it is ideal for medium head ranges (50m to 400m). Single unit output ranges from tens of kilowatts to hundreds of thousands of kilowatts, with maximum outputs exceeding 700,000 kilowatts.
100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 0
Application Scenarios
01 Application scenario 02 Application scenario
03 Application scenario 04 Application scenario
100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 1
Our Advantages
  • 20+ years of customization experience with strict quality control
  • Outstanding safety and exceptional cooling performance
  • High efficiency and energy conservation with minimal system failure points
  • Broad applicability for mixed-flow, axial-flow, and other turbine types
  • Adaptable to various operating conditions in hydropower and pumped storage
Hydropower Plant Services
  • Exploration and design of hydropower plants
  • Design and manufacturing of turbine generator sets
  • EPC for electromechanical equipment (including water conveyance systems)
  • Pre-sales services, training, and technical consultancy
  • Installation, commissioning guidance, and maintenance services
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are a hydro turbine generator manufacturer with over 15 years of experience located in Sichuan.
Q: What kind of water turbine should I choose?
A: We determine the solution based on your water head, flow rate, voltage level, frequency, and automation requirements.
Q: Can you do EPC for hydro power plants?
A: Yes, we handle design, production, installation, and dispatch technicians for equipment setup.
100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 2 100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 3 100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 4 100kw Francis Hydro Turbine Generator 400V-6300V Stainless Steel Runner 5
