Francis Hydro Turbine 50kW-20MW Capacity 400V-6300V Brushless Generator
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 50000 |
|
Detail Information |
|||
| Model NO.: | ZDJJP137 | Output Type: | DC |
|---|---|---|---|
| Type: | Horizontal Hydro Generator | Bearing Support: | Hanging Type |
| Speed: | Low Speed | Bearing Number: | 2 |
| Runner Material: | Stainless Steel | Efficiency: | Up To 90% |
| Insulation Class: | F/F | Capacity: | 50kw-20MW |
| Generator Type: | Brushless | Voltage: | 400V-6300V |
| Turbine: | Francis, Pelton, Turgo, Kaplan | Specification: | 300CMx200cmx150cm |
| Production Capacity: | 200sets Per Year | ||
| Highlight: | Francis Hydro Turbine 50kW capacity,Francis Hydro Turbine brushless generator,Francis Hydro Turbine 400V-6300V |
||
Product Description
6100kw Micro Mini Small Generator Turbine Francis Kaplan Pelton Turgo Water Turbine
Product Description
Micro/small/mini power generator turbine Kaplan Pelton Turgo Francis water turbine
Technical Specifications
| Water head | 10m - 700m |
|---|---|
| Power range | 50kW - 20MW |
| Frequency | 50Hz / 60Hz |
| Generator voltage | 400V, 800V, 6300V, 10500V |
| Layout mode | Horizontal or vertical |
| Material | Stainless steel ZG0Cr13Ni4Mo |
| Excitation | Brushless or static excitation system |
| Lifespan | 50 years |
| Runner diameter | 0.35m - 4m |
| Generator insulation | F/F |
The Francis turbine features a compact structure and high efficiency, capable of adapting to a wide range of water heads. It is one of the widely used turbine types in various countries around the world. When water flows through the runner of this turbine, it enters radially and exits axially, so it is also known as a radial-axial turbine.
It is suitable for a water head range from 20 meters to 700 meters. With a simple structure, stable operation, and high efficiency, it is generally used within the medium head range (50 meters to 400 meters). The output of a single unit ranges from tens of kilowatts to hundreds of thousands of kilowatts. Currently, the maximum output of this type of turbine has exceeded 700,000 kilowatts, making it one of the most widely used turbines. In China, a 700 megawatt unit has been put into operation at the Three Gorges, and the Xiangjiaba Dam employs 800 megawatt Francis turbines.
Our Advantages
Our company boasts a rich history spanning over two decades, with a steadfast focus on customization services, dedicated to fulfilling our clients' unique needs to the fullest extent. We consistently prioritize our clients' specific requirements, ensuring that every detail in the design and manufacturing process strictly adheres to their expectations.
- Exceptional safety standards for reliable operation
- Superior cooling performance for stable operation under various conditions
- High energy efficiency with significant reduction in operational costs
- Minimal system failure points due to advanced design and manufacturing
- Broad applicability across different operating conditions and requirements
Hydropower Plant Services
- Exploration and design of hydropower plants
- Design and manufacturing of turbine generator sets
- EPC (Engineering, Procurement, and Construction) for electromechanical equipment
- Pre-sales services for hydropower plants
- Training services for hydropower plants
- Technical consultancy for hydropower plant operations
- Installation and commissioning guidance
- Maintenance services for hydropower plants
Frequently Asked Questions
Q: Are you a trading company or a manufacturer?
A: We are a hydro turbine generator manufacturer with over 15 years of experience. Our factory is in Sichuan, about 2 hours drive from Shuangliu Airport.
Q: What kind of water turbine should I choose?
A: We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, and automation level to recommend the best solution.
Q: Can you do the EPC for the hydro power plant?
A: Yes, we can design, produce and install the equipment, and will dispatch technicians for installation.
Q: What is the packing of the equipment?
A: We use wooden boxes to protect the product during shipping.
Q: Who can help if my turbine shuts down?
A: Our engineers are available 24/7 to troubleshoot and resolve any issues, either remotely or on-site.
