50kW-20MW Francis Hydro Turbine Generator with 90% Efficiency
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 50000 |
|
Detail Information |
|||
| Model NO.: | ZDJJP132 | Output Type: | DC |
|---|---|---|---|
| Type: | Horizontal Hydro Generator | Bearing Support: | Hanging Type |
| Speed: | Low Speed | Bearing Number: | 2 |
| Runner Material: | Stainless Steel | Efficiency: | Up To 90% |
| Insulation Class: | F/F | Capacity: | 50kw-20MW |
| Generator Type: | Brushless | Voltage: | 400V-6300V |
| Turbine: | Francis, Pelton, Turgo, Kaplan | Specification: | 300CMx200cmx150cm |
| Production Capacity: | 200sets Per Year | ||
| Highlight: | 50kW Francis hydro turbine generator,20MW hydro turbine with warranty,Francis turbine 90% efficiency |
||
Product Description
5700kw Micro Mini Small Generator Turbine Francis Kaplan Pelton Turgo Water Turbine
Product Description
Micro/small/mini power generator turbine Kaplan Pelton Turgo Francis water turbine
Detailed Specifications
| Water head | 10m - 700m |
|---|---|
| Power range | 50kW - 20MW |
| Frequency | 50Hz / 60Hz |
| Generator voltage | 400V, 800V, 6300V, 10500V |
| Layout mode | Horizontal or vertical |
| Material | Stainless steel ZG0Cr13Ni4Mo |
| Excitation | Brushless or static excitation system |
| Lifespan | 50 years |
| Runner diameter | 0.35m - 4m |
| Generator insulation | F/F |
Product Features
The Francis turbine features a compact structure and high efficiency, capable of adapting to a wide range of water heads. It is one of the widely used turbine types globally. Water flows through the runner radially and exits axially, making it a radial-axial turbine.
Suitable for water heads from 20 meters to 700 meters, with simple structure, stable operation, and high efficiency. Typically used in medium head ranges (50-400 meters), with single unit outputs from tens of kilowatts to hundreds of thousands of kilowatts.
Application Scenarios
|
|
Our Advantages
- 20+ years of customization experience
- Exceptional safety and cooling performance
- High energy efficiency and conservation
- Minimal system failure points
- Broad applicability across turbine types
- Adaptable to various operating conditions
Hydropower Plant Services
- Exploration and design of hydropower plants
- Design and manufacturing of turbine generator sets
- EPC for electromechanical equipment
- Pre-sales and training services
- Technical consultancy and maintenance
- Installation and commissioning guidance
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are a hydro turbine generator manufacturer with over 15 years of experience. Our factory is located in Sichuan.
Q: What kind of water turbine should I choose?
A: We need water head, flow rate, voltage level, frequency, and operation details to recommend the best solution.
Q: Can you do EPC for hydro power plants?
A: Yes, we handle design, production, and installation, dispatching technicians for equipment setup.
