Design Head 200m 600m Pelton Water Wheel Capacity 700kW Hydropower Turbine for Mountainous Region Electricity Production
Product Details:
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | CJA-2025 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 50000 |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Set Per Unit |
|
Detail Information |
|||
| Tubine Material: | Q345-B | Nozzle: | Single |
|---|---|---|---|
| Efficiency: | Up To 90% | Generator Output Voltage: | 400V, 6.3KV, Or 10.5KV AC |
| Speed: | Variable, Typically 300 To 1000 RPM | Runner Material: | Stainless Steel |
| Advantages: | High Strength\Anti Corrosion | Design Head: | 200m-600m |
| Highlight: | Pelton water wheel hydropower turbine,700kW Pelton hydro turbine,mountainous region electricity production turbine |
||
Product Description
Product Description:
The Pelton Hydro Turbine is a highly efficient and robust hydroelectric power generation solution designed to harness the kinetic energy of water through impulse action. As a distinguished Hydro Jet Turbine, it operates on the principle of converting the energy of a high-velocity water jet into mechanical energy with outstanding efficiency. This makes it an ideal choice for locations where water is available at high head and relatively low flow rates.
One of the key features of this Pelton Hydro Turbine is its variable speed range, typically between 300 to 1000 RPM. This flexibility in rotational speed allows the turbine to adapt to varying water flow conditions and optimize power output. The variable speed capability also aids in maintaining grid stability and ensures efficient operation under different load demands. Coupled with a single nozzle design, the turbine precisely directs the water jet onto the turbine buckets, maximizing energy transfer and minimizing losses.
The turbine is engineered to handle a water flow rate of 0.76 cubic meters per second (M³/s), making it suitable for medium-scale hydroelectric projects. The flow rate is carefully matched with the turbine's design parameters to ensure optimal performance and longevity. This flow capacity, combined with the impulse action of the water jet, enables the turbine to generate a substantial capacity of 700 kW, making it a reliable power source for small communities, industrial applications, and remote installations.
Constructed from high-quality Q345-B material, the Pelton Hydro Turbine boasts exceptional strength, durability, and resistance to wear and corrosion. Q345-B steel is known for its excellent mechanical properties, including good weldability and toughness, which are essential for the demanding operating conditions of hydro turbine components. This material choice ensures a long service life and minimal maintenance requirements, thereby reducing operational costs and downtime.
As a Water Impulse Turbine, the Pelton design differs fundamentally from axial-flow turbines. While axial-flow turbines operate by allowing water to flow parallel to the shaft, the Pelton turbine uses the water jet to impact the buckets mounted around the periphery of a wheel, converting water's kinetic energy into rotational energy through impulse action. This design is particularly effective in high-head, low-flow scenarios where axial-flow turbines may not be as efficient or feasible.
The single nozzle configuration of the Pelton Hydro Turbine simplifies the water delivery system while maintaining precise control over the jet velocity and direction. This results in improved hydraulic efficiency and ease of operation. The nozzle is designed to withstand high pressures and turbulent flows, ensuring consistent performance even under fluctuating water supply conditions.
In comparison to other turbine types, such as axial-flow turbines, the Pelton Hydro Turbine offers distinct advantages in specific environments. Its impulse-based operation allows it to function effectively in locations with steep water heads, where the potential energy of falling water can be fully exploited. This makes the Pelton turbine a preferred choice for mountainous regions and hydroelectric setups requiring compact and efficient power generation units.
Overall, the Pelton Hydro Turbine represents a perfect blend of engineering precision, material excellence, and operational flexibility. Its variable speed capability, coupled with a 0.76 M³/s water flow handling capacity and a robust single nozzle design, ensures that it delivers reliable 700 kW power output consistently. Constructed from Q345-B steel, it stands resilient against the rigors of hydroelectric power generation, offering sustainable and efficient energy production. Whether deployed as a standalone Hydro Jet Turbine or integrated into a larger hydroelectric system, this Pelton Hydro Turbine is a testament to advanced water impulse turbine technology and a valuable asset in the pursuit of renewable energy.
Features:
- Product Name: Pelton Hydro Turbine
- Nozzle: Single
- Design Head: 200m-600m
- Capacity: 700kW
- Bucket Design: Double-cup or Spoon-shaped
- Advantages: High Strength and Anti Corrosion
- Type: Reaction Hydro Turbine
- Suitable for High-Pressure Turbine applications
- Also known as Pelton Water Wheel
Technical Parameters:
| Advantages | High Strength, Anti Corrosion |
| Runner Material | Stainless Steel |
| Generator Output Voltage | 400V, 6.3KV, Or 10.5KV AC |
| Water Flow | 0.76 M³/s |
| Speed | Variable, Typically 300 To 1000 RPM |
| Bucket Design | Double-cup Or Spoon-shaped |
| Nozzle | Single |
| Maintenance | Low To Moderate |
| Rated Flow | 0.75 M3/s |
| Efficiency | Up To 90% |
Applications:
The Wawushan Pelton Hydro Turbine, model number CJA-2025, is a highly efficient water impulse turbine designed to harness the kinetic energy of water jets for power generation. Originating from China and certified with ISO9001, this turbine is ideal for a variety of hydroelectric applications, delivering an efficiency of up to 90%. Its robust design and reliable performance make it suitable for both small and medium-scale hydropower projects.
This water jet turbine operates with a rated flow of 0.75 cubic meters per second, utilizing a single nozzle to direct high-velocity water jets onto its Pelton wheel. Its variable speed, typically ranging from 300 to 1000 RPM, allows for optimal energy conversion under fluctuating water flow conditions. The generator output voltage options of 400V, 6.3KV, or 10.5KV AC provide flexibility for integration into different power systems.
The Pelton Hydro Turbine is particularly well-suited for mountainous or hilly regions where high-head water sources are available. Its water impulse turbine mechanism makes it an excellent choice for sites with steep water drops, converting the potential energy of falling water into mechanical energy efficiently. This contrasts with axial-flow turbines, which are generally used in low-head, high-flow scenarios, highlighting the Pelton turbine’s unique applicability.
Furthermore, the turbine’s compact design and reliable operation make it an ideal option for remote or off-grid locations requiring sustainable and renewable energy solutions. It can be deployed in rural electrification projects, small hydroelectric power stations, and industrial facilities seeking to reduce carbon footprints by utilizing clean water energy.
With a minimum order quantity of just one unit, a competitive price of 50,000 USD, and a delivery time of six months, Wawushan provides flexible purchasing options supported by payment terms via L/C. Their supply ability of 100 sets per unit ensures that the turbine can meet both individual and bulk project demands effectively.
In summary, the Wawushan CJA-2025 Pelton Hydro Turbine stands out as a reliable water impulse turbine suitable for various application occasions and scenarios, including high-head hydropower generation, remote power supply, and sustainable energy projects. Its design complements other turbine types like axial-flow turbines, expanding the range of solutions available for hydroelectric power generation.
Customization:
Introducing the Wawushan Pelton Hydro Turbine, model number CJA-2025, a high-efficiency turbine designed to deliver exceptional performance and durability. Manufactured in China and certified with ISO9001, this water jet turbine is built to meet the highest quality standards.
Constructed with high-strength Q345-B turbine material and featuring anti-corrosion properties, the Pelton turbine ensures long-lasting operation even in challenging environments. The nozzle ring is made of premium stainless steel 0Cr13Ni4Mo (CA6NM), enhancing resistance to wear and corrosion, while the single nozzle design optimizes water flow for maximum efficiency.
The runner material is also stainless steel, contributing to the robustness and longevity of the turbine. With a minimum order quantity of just one unit and a competitive price of $50,000, this water jet turbine offers excellent value for hydroelectric power projects.
Wawushan guarantees a supply ability of 100 sets per unit, with a delivery time of 6 months and payment terms via L/C, providing reliable service and timely fulfillment. Choose the Wawushan Pelton Hydro Turbine for a high-efficiency turbine solution that excels in performance and durability.
Support and Services:
Our Pelton Hydro Turbine product is backed by comprehensive technical support and services designed to ensure optimal performance and longevity. We provide expert guidance during installation, commissioning, and operation phases to maximize efficiency and reliability.
Our technical support team offers detailed consultation on turbine selection, customization, and integration with existing hydroelectric systems. We also provide regular maintenance schedules, troubleshooting assistance, and performance monitoring to help prevent downtime and extend the turbine's operational life.
In addition, we offer training programs for operational staff to enhance their understanding of turbine mechanics and maintenance procedures. Spare parts availability and retrofit services are also part of our commitment to supporting your Pelton Hydro Turbine throughout its lifecycle.
Whether you require on-site assistance or remote support, our dedicated team is equipped to respond promptly to your technical needs, ensuring continuous and efficient hydroelectric power generation.
