Dual Nozzles Pelton Hydro Turbine with Stainless Steel 0Cr13Ni4Mo Nozzle Ring for 1-200 MW Power Capacity
Product Details:
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | CJA-202511 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 50000 |
| Packaging Details: | Standard |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Set Per Unit |
|
Detail Information |
|||
| Nozzle Number: | Dual Nozzles | Rated Speed: | 750r/min |
|---|---|---|---|
| Water Head: | 100m-800m | Runner Type: | Single Or Multi-Jet |
| Nozzle Ring: | Stainless Steel 0Cr13Ni4Mo (CA6NM) | Efficiency: | Up To 90% Or Higher |
| Head: | 50-1000 M | Productname: | Pelton Hydro Turbine |
| Highlight: | Dual Nozzles Pelton Hydro Turbine,Stainless Steel 0Cr13Ni4Mo Nozzle Ring Hydro Jet Turbine,1-200 MW Power Capacity Water Impulse Turbine |
||
Product Description
Double Cup or Split Bucket Pelton Hydro Turbine
The Pelton Hydro Turbine is a highly efficient reaction turbine engineered for high-head, high-pressure hydroelectric applications. With power capacity ranging from 1 to 200 MW, this versatile solution accommodates projects from small-scale installations to major power plants.
Advanced Turbine Design
Operating as a high-pressure hydro jet turbine, this system converts the kinetic energy of high-velocity water jets into mechanical energy with exceptional efficiency. The dual nozzle configuration ensures precise water jet direction onto the turbine runner, maximizing energy transfer and optimizing performance.
Premium Material Construction
Nozzles are mounted on a stainless steel 0Cr13Ni4Mo (CA6NM) ring, providing outstanding mechanical properties and superior corrosion resistance. This material selection guarantees enhanced durability and extended service life under demanding hydroelectric conditions.
Key Features
- Single or multi-jet runner type configuration
- Flow rate capacity: 1-200 m³/s
- Operating head range: 50-1000 meters
- Design head optimization: 200-600 meters
- High-strength construction with anti-corrosion properties
- Efficient water jet turbine design for optimal energy conversion
- Durable Pelton water wheel suitable for various hydropower applications
- Reliable performance under diverse operating conditions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Pelton Hydro Turbine |
| Type | Impulse Turbine |
| Runner Type | Single or Multi-Jet |
| Nozzle Number | Dual Nozzles |
| Nozzle Ring Material | Stainless Steel 0Cr13Ni4Mo (CA6NM) |
| Design Head | 200m-600m |
| Operating Head | 50-1000 M |
| Water Head | 100m-800m |
| Bucket Design | Double Cup or Split Bucket |
| Noise Level | Low |
Applications
The Wawushan Pelton Hydro Turbine (Model CJA-2025) is an advanced impulse turbine ideal for high-head hydroelectric projects. Certified with ISO9001 and manufactured in China, this turbine operates at 750r/min with low noise emissions, ensuring both performance excellence and environmental compliance.
This turbine excels in mountainous regions and steep terrain where high-pressure, low-volume water flows are available. The double cup or split bucket design optimizes water impulse, maximizing energy extraction from hydro jets.
Ideal Applications Include:
• Isolated rural electrification projects
• Remote industrial facilities
• Small community power generation
• Mini and micro hydropower schemes
• Environmentally sensitive areas
• Isolated rural electrification projects
• Remote industrial facilities
• Small community power generation
• Mini and micro hydropower schemes
• Environmentally sensitive areas
Customization & Ordering
Model: CJA-2025
Design Head: 200m-600m
Flow Rate: 1-200 m³/s
Rated Speed: 750r/min
Minimum Order: 1 set
Price: $50,000 per unit
Delivery Time: 6 months
Supply Capacity: 100 sets per unit time
Payment Terms: L/C supported
Design Head: 200m-600m
Flow Rate: 1-200 m³/s
Rated Speed: 750r/min
Minimum Order: 1 set
Price: $50,000 per unit
Delivery Time: 6 months
Supply Capacity: 100 sets per unit time
Payment Terms: L/C supported
Technical Support & Services
Our comprehensive support package includes detailed installation manuals, operational training, and customized maintenance schedules. We provide troubleshooting assistance, performance monitoring, and timely repairs to minimize operational downtime.
Additional services include upgrades, modernization options, and readily available spare parts to maintain optimal performance and adapt to evolving energy requirements.
