Vertical Layout 9000KW Capacity Stainless Steel Runner Kaplan Hydro Turbine Generator for Power Plants
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | ZDJP-018 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 180 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Runner Material: | Stainless Steel | Voltage: | 6300V |
|---|---|---|---|
| Layout: | Vertical | Runner Blade: | Adjustable |
| Runner Diameter: | 2.5 M | Flow: | 28.67 M³/s |
| Highlight: | 9000kw Kaplan Hydro Turbine,50HZ adjustable Kaplan Hydro Turbine,9000kw vertical kaplan turbine |
||
Product Description
Kaplan Hydro Turbine - Axial Flow Power Generation
Vertical Micro 9000kw Kaplan Water Turbine Generator designed for power plant applications, featuring axial flow technology where water direction remains constant as it passes through the rotor blades.
Product Overview
The Kaplan turbine is an axial-flow reaction turbine featuring adjustable blades within a tube structure. This design maintains constant flow direction across the rotor, utilizing both kinetic and pressure energy from water for optimal blade rotation in hydro-power stations.
Working Principle
Water enters from the pen-stock into a specially shaped scroll casing that preserves flow pressure. Adjustable guide vanes direct water to the runner blades, with the flow taking a 90-degree turn to align axially with the blades. The runner blades feature a twist along their length to maintain optimal angle of attack across all sections, maximizing efficiency. Water then enters the draft tube where kinetic energy converts to pressure energy, increasing water pressure. The resulting turbine rotation drives generator shafts for electricity production.
Key Applications
- Global electrical power production applications
- Superior efficiency at low water head and high flow rates
- Compact design with simplified construction
- Exceptional efficiency compared to other hydraulic turbines
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Vertical Micro 9000kw Kaplan Water Turbine Generator |
| Water Head | 32.0m |
| Runner Diameters | 2.5m |
| Capacity | 9000KW |
| Frequency | 50HZ |
| Generator Voltage | 6300V |
| Layout Pattern | Vertical |
| Blade Material | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Company Advantages
- 20+ years of industry experience with 150+ equipment installations annually
- Complete hydro power plant solutions from water to wire
- Extensive international project experience including France, Japan, USA, South Africa, Sri Lanka, Iran, and Southeast Asia
- Custom hydro power generator design and manufacturing with voltages from 400V to 6.3KV
Frequently Asked Questions
Are you a trading company or manufacturer?
We are a hydro turbine generator manufacturer with over 20 years of experience. Our factory is located in Sichuan, approximately 2 hours from Shuangliu Airport. We welcome factory visits for detailed insights into our operations.
How do I select the right water turbine?
We require water head, flow rate, voltage level, frequency, grid connection type (on-grid/off-grid), and automation level specifications to develop the optimal solution for your requirements.
Can you provide EPC services for hydro power plants?
Yes, we offer comprehensive Engineering, Procurement, and Construction services including equipment design, production, installation, and technical support with on-site personnel.
Product Images
