Vertical Micro Mini Small Water Francis Pelton Turgo Kaplan Hydro Hydraelectric Turbine Permanent Magnet Generator alter
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | ZDJP-019 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 180 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Runner Material: | Stainless Steel | Voltage: | 6300V |
|---|---|---|---|
| Layout: | Vertical | Runner Blade: | Adjustable |
| Runner Diameter: | 1.7 M | Flow: | 19.77 M³/s |
| High Light: | Vertical Mini Kaplan Hydro Turbine,Power Plant Kaplan Hydro Turbine,6300V small kaplan turbine |
||
Product Description
Vertical Min 4500kw Kaplan Water Turbine Generator For Power Plant
overview
A Kaplan turbine is basically a propeller with adjustable blades inside a tube. It is an axial-flow turbine, which means that the flow direction does not change as it crosses the rotor.
Kaplan Turbine works on the principle of axial flow reaction. In axial flow turbines, the water flows through the runner along the direction parallel to the axis of rotation of the runner. The water at the inlet of the turbine possesses both kinetic energy as well as pressure energy for effective rotation the blades in a hydro-power station.
Disadvantage of Kaplan Turbine
The only disadvantage of kaplan turbine is cavitation, which occurs due to pressure drop in draft tube. Use of draft tube and proper material generally stainless steel for the runner blades may reduce the cavitation problem to a greater extent.
Specification
| Name | Vertical Min 4500kw Kaplan Water Turbine Generator For Power Plant |
| Water Head | 29.0m |
| Runner Diameters | 2.5m |
| Capacity | 4500KW |
| Frequency | 50HZ |
| Generator Voltage | 6300V |
| Layout pattern | vertical |
| Material(blades) | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Why choose us?
1. More than 20 years of industry experience, install commissioning more than 150 equipment each year
2. Provide complete proposal for hydro power plant from water to wire
3. Abundant foreign power plant project implementation experience such as France, Japan, USA, South Africa, Sri Lanka, Iran, Southeast Asia
4. Design and manufacture of hydro power generator with voltage 400V,6.3KV . capacity exceed 1000kw with 400V
FAQ
1.You are a trading company or a manufacture?
We are a hydro turbine generator manufacture with over 20 years of experiences, Our factory is in the Sichuan you will take 2 hours driving after you reach Shuangliu Airport, pay a visit to our factory you will know more about us.
2.What Kind of water turbine should I choose?
We need to know water head, flow rate, voltage level, frequency, on-grid or off-grid running, automation level from you to work out the solution
3: Can you do the EPC for the hydro power plant?
Yes, We can design, producing and install the equipment, we will dispatch technologist and workers to install the equipment.
